SMD Inductors for Class D DBL7280H NEW AEC-Q200 2 in 1
| Shape |
|
| Recommended Land pattern |
|
| Catalog |
|
| Graph of Characteristics | |
| General specification | |
| Taping information | |
| Buy Now |  |
Features
- Space reduction is realized by 2 in 1 construction
- Low distortion and high-quality sound by low loss material and OFC (Oxygen-Free Copper) wire
- Compact size using flat wire
- High current, Low resistance
- AEC-Q200 compliant spec available upon request
- Operating temperature：-40℃～+125℃(The self-heating is included)
Applications
- AudioVisual
- Automotive
- Home Electronics
- Others
TV and Monitor, Mini component, AV amplifier, Amplifier for profes
Car Autio, Car Navigation
Games
Power Supply
Electrical Characteristics
| Part Number | Inductance (µH) |
DCR (mΩ) max. | DC Saturation Allowable Current (A) | Temperature Rise Allowable Current (A) |
|---|---|---|---|---|
| DBL7280H-1R0M | 1 ± 20% | 10.5 | 12.2 | 5 |
| DBL7280H-3R3M | 3.3 ± 20% | 23 | 5.8 | 3.4 |
| DBL7280H-100M | 10 ± 20% | 62.5 | 3.1 | 2 |
- Inductance Measuring Condition:100kHz,1V
- DC saturation allowable current:The current value which inductance decrease within 25% from the initial value
- Temperatue rise allowable current:The rise in temperature of core surface is within 40℃
Graph of Characteristics
Characteristics of DC Superposition
