SMD Inductors for Class D DBL5674H
NEW AEC-Q200 2 in 1
Mag
Product Info.
Tech Info.
General Info.
Features
- Optimized for 14V27W(3.6A)
- Space reduction is realized by 2 in 1 construction
- The optimal design realizes high quality sound and low distortion
- Smallest class of product
- AEC-Q200 compliant
- Operating temperature：-40℃～+125℃(The self-heating is included)
Applications
- AudioVisual TV and Monitor, Mini System, AV Amplifier, for Professionals
- Automotive Car Audio, Car Navigation
- Home Electronics Games
- Others Power Supply
Electrical Characteristics
| Part Number | Inductance(µH) | DCR (mΩ) | DC Saturation Allowable Current (A) | Temperature Rise Allowable Current (A) | |
|---|---|---|---|---|---|
| Max | Typical | ||||
| DBL5674H-3R3M | 3.3 ± 20% | 46.6 | 38.8 | 4.9 | 2.9 |
- Inductance Measuring Condition:100kHz,1V
- DC saturation allowable current:The current value which inductance decrease within 25% from the initial value
- Temperature rise allowable current:The rise in temperature of core surface is within 40℃
