Pulse Drive transformer for Automotive Equipment VHK1550V
NEW AEC-Q200
Mag
Product Info.
Tech Info.
General Info.
Features
- For signal transmission
- High Withstand Voltage ～AC 3500Vrms
- Creepage distance and space distance (primary side - secondary side) of 13mm Min.
- Low height (5mm MAX.)
- Low leakage flux
- AEC-Q200 compliant
- Operating temperature：-40℃～+150℃(The self-heating is included)
Applications
- Automotive ECU
- Others Power Supply, Energy
Specification Sheet
| Type | Appearance | Core Shape | Magnetic Structure | Number of Terminals (pcs) |
Voltage Rating (V) Max. |
Output Power (W) |
Mounting Area (mm²) |
Height (mm)Max. |
Frequency | Topology |
|---|---|---|---|---|---|---|---|---|---|---|
| VHK1550V |
 |
UI |
 |
6 | AC3500 | 0.8 | 375 | 6 | 2000 | フォワード/プッシュプル/パルス通信 |
カテゴリー: パルストランス
