Metal Composite Power Inductors XRJ0754
NEW AEC-Q200
Product Info.
Tech Info.
General Info.
Features
- Realization of small size and high current specifications by metallic magnetic material.
- Low DCR, high saturation current
- Decreased acoustic noise by there are no air gaps.
- Low inductance variance in temperature environments.
- Operating temperature：-40℃～+150℃(The self-heating is included)
Applications
- AudioVisual TV and Monitor, Mini System, AV Amplifier, for Professionals, Camera, Recorder
- Automotive Car Audio, Car Navigation, ECU, LED Headlights
- Computer & Peripheral Device Computer, Printer(MFP), Industorial Machines
- Home Electronics LED Lights
- Others Power Supply, FA, Medical, Energy
Electrical Characteristics
| Part Number | Inductance(µH) | DCR (mΩ) | DC Saturation Allowable Current (A) | Temperature Rise Allowable Current (A) | |
|---|---|---|---|---|---|
| Max | Typical | ||||
| XRJ0754-2R2M | 2.2 ± 20% | 6.4 | 5.4 | 15 | 13 |
| XRJ0754-3R3M | 3.3 ± 20% | 9.7 | 8.5 | 12.5 | 12.5 |
| XRJ0754-4R7M | 4.7 ± 20% | 10.5 | 9.2 | 9.5 | 9.5 |
| XRJ0754-5R6M | 5.6 ± 20% | 17.2 | 14.1 | 9 | 8.5 |
| XRJ0754-6R8M | 6.8 ± 20% | 18 | 16 | 7.5 | 8 |
| XRJ0754-100M | 10 ± 20% | 25 | 22 | 6 | 5 |
- Inductance Measuring Condition:100kHz,1V
- DC saturation allowable current:The current value which inductance decrease 30% from the initial value
- Temperature rise allowable current:The rise in temperature of core surface is 40℃
