DC/DC Converter Transformer for Automotive Equipment VEC1911B
AEC-Q200
Mag
Features
- For battery charger for HEV / EV
- For battery management system etc.
- VEC1911B：High heat resistance・High withstand voltage (～AC 2500Vrms)
- AEC-Q200 compliant
- Operating temperature：-40℃～+150℃(The self-heating is included)
Applications
Specification Sheet
| Type | Appearance | Core Shape | Magnetic Structure | Number of Terminals (pcs) |
Voltage Rating (V) Max. |
Output Power (W) |
Mounting Area (mm²) |
Height (mm)Max. |
Frequency | Topology |
|---|---|---|---|---|---|---|---|---|---|---|
| VEC1911B |
 |
EPC |
 |
10 | AC2500 | 16.2 | 567 | 10.8 | 500 | フライバック |
