High Reliability Leaded Inductors CVE2622C
AEC-Q200
Mag
Product Info.
Tech Info.
General Info.
Features
- Greatly improved current characteristics
- Magnetically Shielded structure with low magnetic flux leakage
- Low-resistance, and support high currents by using flat wire
- Excellent in withstand voltage
- AEC-Q200 compliant
- Operating temperature：-40℃～+150℃(The self-heating is included)
- Part numbers listed in the Analog Devices LTC7871 and LTC7060 Datasheets
Applications
- AudioVisual Mini System, AV Amplifier, for Professionals
- Automotive Car Audio, ECU
- Home Electronics Home Electronics
- Others Power Supply, FA, Medical, Energy
Electrical Characteristics
| Part Number | Inductance(µH) | DCR (mΩ) | DC Saturation Allowable Current (A) | Temperature Rise Allowable Current (A) | |
|---|---|---|---|---|---|
| Max | Typical | ||||
| CVE2622C-3R3M | 3.3 ± 20% | 2 | 1.8 | 85 | 33 |
| CVE2622C-4R7M | 4.7 ± 20% | 2 | 1.8 | 59 | 33 |
| CVE2622C-6R8M | 6.8 ± 20% | 2 | 1.8 | 41 | 33 |
| CVE2622C-100M | 10 ± 20% | 2 | 1.8 | 28 | 33 |
| CVE2622C-150M | 15 ± 20% | 2 | 1.8 | 18 | 33 |
| CVE2622C-220M | 22 ± 20% | 2 | 1.8 | 12 | 33 |
| CVE2622C-330M | 33 ± 20% | 2 | 1.8 | 7 | 33 |
- Inductance Measuring Condition:100kHz,1V
- DC saturation allowable current:The current value which inductance decrease 10% from the initial value
- Temperature rise allowable current:The rise in temperature of core surface is 40℃
Current characteristic graph
Characteristics of DC Superposition
Characteristics of Temperature Rise
