High Reliability SMD Inductors CDG3833CB
NEW AEC-Q200
Mag
Product Info.
Tech Info.
General Info.
Features
- Tight Inductance tolerance ±15%
- SMD Inductors for High Current Applications
- Low DCR, high saturation current
- AEC-Q200 compliant
- Operating temperature：-40℃～+150℃(The self-heating is included)
Applications
- Automotive ECU
- Computer & Peripheral Device Computer
- Others Power Supply
Electrical Characteristics
| Part Number | Inductance(nH) | DCR(mΩ) max. | DC Saturation Allowable Current (A) | Temperature Rise Allowable Current (A) |
|---|---|---|---|---|
| CDG3833CB-45NL | 45 ± 15% | 0.6 | 63.4 | 32.1 |
| CDG3833CB-60NL | 60 ± 15% | 0.6 | 52.8 | 32.1 |
| CDG3833CB-65NL | 65 ± 15% | 0.6 | 46.4 | 32.1 |
| CDG3833CB-80NL | 80 ± 15% | 0.6 | 41.3 | 32.1 |
- Inductance Measuring Condition:100kHz,1V
- DC saturation allowable current:The current value which inductance decrease 20% from the initial value
- Temperature rise allowable current:The rise in temperature of core surface is 40℃
